Priručnik Candy CH64FX Ploča za kuhanje

Priručnik

07 GB

. HOB COOARE ADVICE

Using good quality cookware is critical for setting

the best performance from your hob.

• Ensure that the base of the pot or pan is dry : when filling pans

with liquid or using one that has been stored in the refrigerator, ensure

that the base of the pan is completely dry before placing it on the hob.

This will help to avoid staining the hob.

• Always use good uality cookware with perfectly flat and thick

bases : using this type of cookware will prevent hot spots that cause

food to stick. Thick metal pots and pans will provide an even

distribution of heat.

• Use pans whose diameter is wide enough to completely cover

the surface unit : the size of the pan should be no smaller than the

heating area. If it is slightly wider the energy will be used at its

maximum efficiency.

THE CHOICE OF COOARE - The following information will help

you to choose cookware which will give good performance.

Because of its low melting point, thin aluminium should not be used.

Copper Bottom / stoneware: heavy weight recommended. Good

performance, but copper may leave residues which can appear as

scratches. The residues can be removed, as long as the hob is

cleaned immediately. However, do not let these pots boil dry.

Overheated metal can bond to glass hobs. An overheated copper pot

will leave a residue that will permanently stain the hob.

Porcelain/enamel : Good perfomance only with a thiny smooth, flat

base.

Aluminium : heavy weight recommended. Good conductivity.

Aluminium residues sometimes appear as scratches on the hob, but

can be removed if cleaned immediately.

Stainless Steel : highly recommended. Especially good with a

sandwich clad base. The sandwich base combines the benefits of

stainless steel (appearance, durability and stability) with the

advantages of aluminium or copper (heat conduction, even heat

Cast Iron : usable, but not recommended. Poor performance. May

scratch the surface.

distribution).

Glass-ceramic : not recommended. Poor performance. May scratch

the surface.

5. USE

Through the "Power management" function, the user can set the

maximum power that can be reached by the hob. Power management

function is only available during first 30 seconds after switch on the

hob. There is even the possibility to repeat this setting switching off

and on the power plug. By setting the desired maximum power, the

hob automatically adjusts the distribution in the various cooking zones

so that this limit is never exceeded; with the added advantage of being

able to simultaneously manage all the zones without overload

problems. The customer can set the maximum power of hob between

2.5 kW and the maximum related power of the hob (this can change

according to the model) (for example if the maximum power of the hob

is 7.2 kW. The maximum power level for setting is between 2.5kW and

7.2kW) At the time of purchase, the hob is set to maximum power. After

connecting the appliance to the electrical power, within 30 seconds

you can set the power level based on the points shown below:

1.- Swtch on hob.

2.- Let touch control fnsh ts ntalzaton process.

4.- After ths moment, ths message wll appear on dsplay.

3.- Before pass 30 seconds touch durng 5 seconds ‘ key.

How to choose power management level

P

P

4

5

0 0

5.- Usng ‘Plus’ and ‘Mnus’ keys Power management value can be

adjusted. In ths example case between 6500 and 2500w. When

requred value s selected, touch at the same tme ‘Plus’ & ‘Mnus’ keys

durng 5 seconds.

6.- When ths process s fnshed, a long beep s heard and a reset s

produced. Start-up process wll be generated agan.

7.- After start-up process, n tmer dsplay ECO power management

wll be showed.

After that, touch control won´t allow any combnaton whch

can exceed ths Eco lmt.

1) If any cooking stage is in position 0, this display will switch OFF

automatically after 10 seconds and the zone OFF sequence will

sound.

4) If only one heater is active and this one is switched off, 4 Short beep

will be heard indicating all cook top is Off.

3) Even lock function is active you can switch OFF a zone.

2) If there is residual heat indication in the display which is OFF, "H" will

be displayed.

Switch ON/OFF a heater zone

To switch ON a heater Touch any heater´s zone during 400 msec.

Long beep will be heard and "0" value will appear in target zone digit,

indicating power level.

1) If any cooking stage is in position 0, this display will switch OFF

automatically after 10 seconds and the zone OFF sequence will

sound.

2) If there is residual heat indication in the display which is ON but in 0

power, "0" will appear changing over.

3) If lock function is active you cannot switch ON a zone.

To switch O a heater Touch any heater´s zone during 1,2 sec. 3

Short beeps will be heard and nothing or "H" value will appear in

target zone digit if residual heat exists. Zone will be OFF.
