English (Original Instructions)

EN

DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET

PACKING LIST

 Lawn mower

 Battery key

 Grassbox

 Mulching plug

 Side discharge deflector

 Operator’s manual

 Knobs

 Bolts

WARNING

If any parts are damaged or missing do not operate

this product until the parts are replaced. Using a

product with damaged or missing parts could result

in serious personal injury.

WARNING

Do not attempt to modify this product or create

accessories not recommended for use with this





possible serious personal injury.

WARNING

Do not insert battery key until assembly is complete

and you are ready to mow. Failure to comply could

result in accidental starting and possible serious

personal injury.

WARNING

To prevent accidental starting that could cause

    

pack from the product when assembling parts.

WARNING

Never operate the mower without the proper safety

devices in place and working. Never operate the

mower with damaged safety devices. Operation of

this product with damaged or missing parts could

result in serious personal injury.

UNFOLDING AND ADJUSTING LOWER HANDLE

See gure 2.

 Pull and rotate the handle knobs 90° on both sides

to loosen the lower handles on both sides.

 Move the lower handles to the operating position.

You may raise or lower the handle to a position

comfortable for you. There are 3 positions for you to

choose. Release the handle knobs to lock the lower

handle into position.

NOTE: Ensure both sides are set at the same position

for proper assembly.

INSTALLING THE UPPER HANDLE

See gure 3.

 Align the mounting holes on the upper handle and the

lower handle. Insert the carriage bolts and use the

knobs to tighten them. Repeat the operation on the

other side.

INSTALLING THE GRASSBOX

See gure 4.

 Lift the rear discharge door.

 Lift the grass catcher by its handle and place under

the rear discharge door so that the hooks on the

grass catcher are seated on the door rod.

 Release the rear discharge door. When installed co



through the openings on the rear discharge door.

INSTALLING THE MULCHING PLUG

See gure 5.

 Lift and hold up the rear discharge door.

 Grasp the mulching plug by its handle and insert it



 Push the mulching plug securely into place.

 Lower the rear discharge door.

INSTALLING SIDE DISCHARGE DEFLECTOR

See gure 6.

NOTE

install the grassbox. The mulching plug should remain

installed.

 Lift the side discharge door.

 Align the hooks on the deflector with the hinge rod

on the underside of the door.

 Lower the deflector until the hooks are secured on

the mulch door hinge rod.

 Release the defl ector and side discharge door.

SETTING BLADE HEIGHT

See gure 7.







for your lawn. The average lawn should be between 38

mm and 51 mm during cool months and between 51

mm and 70 mm during hot months.

2
