ENG - 7

02 PRODUCT OVERVIEW

Front Panel / Top Panel of the Soundbar

1 2 3

Position the product so

that the SAMSUNG logo is

located on the top.

(Multi Function) Button

• In standby mode, press the (Multi Function) button to turn on the Soundbar.

• Press the (Multi Function) button to change the input source.

(Volume) Button

Adjusts the volume.

(Mic On/Off) Button

Press the button to turn the microphone on or off.

4 Display

Displays the product’s status and current mode.

D.IN → HDMI → Wi-Fi → BT

• When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.

• When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

• If you hear sounds from both the TV and Soundbar, go to the Settings menu for the TV audio and change the TV speaker to External Speaker.

Bottom Panel of the Soundbar

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

NETWORK ID SET

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

NETWORK ID SET

HDMI TO TV

(eARC/ARC)

HDMI IN

HDMI OUT

(TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

HDMI TO TV

(eARC/ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

NETWORK ID SET

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

NETWORK ID SET

HDMI TO TV

(eARC/ARC)

HDMI IN

HDMI OUT

(TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

HDMI TO TV

(eARC/ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

NETWORK ID SET

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

NETWORK ID SET

HDMI TO TV

(eARC/ARC)

HDMI IN

HDMI OUT

(TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

HDMI TO TV

(eARC/ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

NETWORK ID SET

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

NETWORK ID SET

HDMI TO TV

(eARC/ARC)

HDMI IN

HDMI OUT

(TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

DIGITAL AUDIO IN

(OPTICAL)

SERVICE

DC 19V

HDMI

HDMI TO TV

(eARC/ARC)

4 5

1 DIGITAL AUDIO IN (OPTICAL)

Connect to the digital (optical) output of an external device. (See page 20)

2 SERVICE

Connect a USB storage device to upgrade the product’s software.

3 DC 19V (Power Supply In)

Connect the AC/DC power adapter. (See page 12)

4 NETWORK

Press to connect to a wireless network (Wi-Fi) via the SmartThings app.

5 ID SET

Press to connect the Soundbar to surround speakers and a subwoofer wirelessly. (The surround speaker is sold separately.)

6 HDMI

Inputs digital video and audio signals simultaneously using an HDMI cable.

Connect to the HDMI output of an external device. (See page 19)
