THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.hotpoint.eu/register

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code in your appliance

• Visiting our website docs.hotpoint.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product's identi cation plate.

EN

Before using the appliance carefully

read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.

Quick guide

Before using the appliance carefully

read the Safety Instruction.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying

cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items. For

optimal drying result, garments should be loaded one by one.

3. Close the door.

4. Press the "On/O" button.

5. Select the most suitable programme

for the type of fabric in

that load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Turn the machine

o by pressing the "On/O" button, open the door and pull the

clothing immediately out to prevent the formation of creases on

laundry.

If the machine is not switched o manually, after about a quarter

of an hour from the end of the cycle , the appliance turns o

automatically to save energy.

Note that some programme/option accords with "Crease Care"

system. This means that for some hours, after the end of the drying

cycle, the drum rotates at regular intervals to prevent the formation

of creases.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

Note that some models perform a nal cool tumble phase, for this

reason the fabrics may not feel hot.

In case of power failure, it is necessary to press the "Start/Pause" button

to restart the cycle.

Opening the door during the cycle

The tumble dryer door can be opened at any time during the cycle

to check progress and remove any garments already dry.

However, since opening the door can extend the drying time, the

recommendation is to keep the door closed throughout the cycle

process to save time and energy.

After closing the door, press the "Start/Pause" button within 15

minutes to resume the machine operation.

FIRST TIME USE

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dryer is xed correctly,

either to the dryer’s water tank, or to your domestic drainage

system.

The dryer must be installed in a room with a temperature

ranging between 5°C and 35°C to ensure proper operation.

Before using the dryer make sure it has been in an upright

position for at least 6 hours.

Should you wish to change the opening side of the door,

please contact our After-sales Service. (See phone number in

the warranty booklet).

3 “

“

3 “

“

END

END

1

3

2

4

10

8

9

5 67

D

D

E

E

M

M

O

O

h

h

h

CONTROL PANEL

1 ON/OFF Button (hold for Reset)

2 Programme Selection Knob

3 Start/Pause

Options Buttons*

4 Crease Care

5 Dryness Level

6 Start Delay

7 Timed Drying

8 Cycle End

9 Gentle (hold for Key Lock)

10 Rapid (hold for Mute)

*Note: some models may have the wording in full instead of the icons.

INDICATORS

Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry

Cycle Phase: Drying - Cool Down - END End of Cycle

Empty water tank - Clean door lter - Clean bottom lter

Refer to troubleshooting section: Failure: Call after sales service
