2

EN

Installation

10

m

m

15 mm

15 mm

15 mm

15 mm

B

A

Where to install the tumble dryer

• Install the dryer far

from gas ranges, stoves,

radiators or hobs, as

flames may damage it.

If the dryer is installed

below a worktop, ensure

there are 10 mm betwe-

en the upper panel of the

dryer and any objects

above it, and 15 mm

between the sides of the machine and the

walls or furniture units adjacent to it. This en-

sures adequate air circulation. Make sure the

air inlets on the rear panel are not blocked or

obstructed.

• You should also make sure that the room

in which the tumble dryer is installed is not

damp, and that it is adequately ventilated.

• ! We do not recommend that the dryer is

installed in a cupboard but the dryer must

never be installed behind a lockable door,

a sliding door or a door with a hinge on the

opposite side to that of the dryer door.

• ! The appliance must be installed with the

rear surface placed against a wall.

Ventilation

This appliance gently dries laundry by taking in cold, clean

and relatively dry air, heating it and passing it through the

fabric. To facilitate the drying process, damp air is expelled at

the rear, through a ventilation hose. When the dryer is in use,

there has to be adequate ventilation to avoid a back flow

of gases into the room from appliances burning other fuels,

including open fires.

Mobile ventilation system

When using the tumble dryer with the mobile ventilation

system, a ventilation hose must be connected. The hose

should be securely fastened to the ventilation hole at the

rear of the appliance (see “Description of the tumble dryer”).

We recommend the hose is connected to an outlet near

the tumble dryer, if possible. If it cannot be installed in a

permanent spot, the tumble dryer will still function perfectly

well if the ventilation hose is passed through a partially-

opened window.

! Make sure you do not point the ventilation hose towards

the air inlet, which is located on the rear of the appliance.

! The ventilation hose should not exceed a maximum length

of 2.4 metres; it should also be shaken frequently to remove

any fluff, dust or water deposits inside it. Make sure you do

not crush the hose.

Fixed ventilation system

We recommend the ventilation hose is connected to a

ventilation system for windows or doors, available from the

retailer which originally sold you the appliance or from your

local spare parts stockist.

Wall ventilation hole

1. Leave an opening in the wall

to the left of the tumble dryer

installation site.

2. Make the hose as short and

straight as possible, in order

to prevent any moisture from

condensing and leaking back

into the appliance.

3. The hole in the wall must

also be straight and pointing

downwards, so that the flow of air coming out is not

impeded.

Areas A and B should be checked frequently, to prevent

the accumulation of fluff or debris, particularly if the tumble

dryer is used very often. The hose adaptor must be fitted

correctly, in order to prevent damp air from coming back into

the room.

Window ventilation hole

The ventilation hole should

be directly behind the dryer in

order to keep the hose as short

as possible.

! Make sure you do not

push the tumble dryer too

far backwards, as this could

lead to the ventilation hose

being crushed, bent or even

disconnected.

! There should be no cuts, kinks or “U”-shaped bends

in the hose, as these could impede ventilation or trap

condensation.

Ventilation through an open window

The end of the hose must be

facing downwards, in order to

prevent the hot, damp air from

forming condensation in the

room or the tumble dryer.

! Make sure that the tumble dryer is adequately ventilated,

and that the end of the ventilation hose is not pointing

towards the air inlet pipe on the rear of the appliance.

! The ventilation hose must always be fitted to ensure

optimum performance.

! Make sure that the ventilation hose and the air inlet vents

are not obstructed or blocked.

! Do not let the tumble dryer recirculate exhaust air.

! Improper use of the tumble dryer may result in fire hazards.

! The air emitted by the tumble dryer must not be expelled in

the same duct as used for the fumes produced by different

appliances which burn gas or other fuels.

! Do not discharge the exhaust air into an extraction system

or any duct with an extractor fan. This will affect the way the

thermal controls operate and can result in a fire hazard.

Electrical connections

Before plugging the appliance into the so-

cket, check the following:

• Make sure your hands are dry.

• The socket must have an earth connec-

tion.

• The socket must be able to withstand the

machine’s maximum power output as indica-

ted on the rating plate (see Description of the

tumble dryer).

• The power supply voltage must fall within

the values indicated on the rating plate (see

Description of the tumble dryer).

• The socket must be compatible with the

dryer’s plug. Should this not be the case,

replace the plug or the socket.

! DO NOT USE EXTENSION CORDS.

! The dryer must not be installed outdoors,

even if the space is sheltered. It can be very

dangerous if exposed to rain or storms.

! Once installed, the dryer’s electrical wire

and plug must be within reach.

! The power cord must not be bent or

squashed.

! If the plug being replaced is a non-rewirable

type, then the cut-off plug must be disposed

of safely. DO NOT leave it where it can be

inserted into a socket and create a shock

hazard.

! The electric cord must be regularly

checked. If the supply cord is damaged, it

must be replaced by the manufacturer, its

service agent or similarly qualified persons in

order to avoid a hazard.

(see Service). New or

longer power cords are supplied at an extra

charge by authorized dealers.

! The manufacturer denies any responsibility

should any of these rules not be followed.

! If in doubt about any of the above

consult a qualified electrician.

Levelling the tumble dryer

The tumble dryer should be installed level in order to

operate correctly.

After installing the tumble dryer in its permanent position,

make sure it is level; check its side-to-side levelling first,

followed by front-to-back.

If the tumble dryer is not perfectly level, use a wooden

block to support it while you adjust the two front feet, up

or down as necessary.

Before you start your dryer

Once the tumble dryer is installed, clean the inside of the

drum before operating it and remove any dirt accumulated

during transportation.
