3
RQT9988
Caution for AC Mains Lead
(For the AC mains plug of three pins)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that
the replacement fuse has a rating of 5-ampere and that it
is approved by ASTA or BSI to BS1362.
Check for the ASTA mark Ï
or the BSI mark Ì on the
body of the fuse.
If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until
a replacement cover is obtained.
A replacement fuse cover can be purchased from your
local dealer.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC
mains plug (figures A and B). Confirm the AC mains plug
fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
Supplied accessories
Check and identify the supplied accessories.
• Product numbers provided in these operating instructions
are correct as of November 2014. These may be subject to
change.
Maintenance
• To clean this system, wipe with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to clean
this system.
• Before using chemically treated cloth, read the
instructions that came with the cloth carefully.
Preparing the remote control
• Use alkaline or manganese battery.
• Install the battery so that the poles (+ and –) align with
those in the remote control.
• Point the remote control at the remote control sensor,
away from obstacles, at a maximum range of 7 m
directly in front of the main unit, within an angle of
approximately 30° to the left and right.
Figure A
Figure B
Fuse cover
Figure A
Fuse
(5 ampere)
Figure B
Fuse
(5 ampere)
∏ (For Continental Europe)
1 x AC mains lead
(K2CQ2YY00119)
∏
(For the United Kingdom and Ireland)
1 x AC mains lead
(K2CT2YY00097)
∏
(For Australia and New Zealand)
1 x AC mains lead
(K2CJ2YY00101)
∏
1 x Remote control
(N2QAYB001018)
∏
1 x Remote control battery
∏
2 x Speaker cables
(REE1713)
∏
([PMX70]) 1 x FM indoor antenna
(RSAX0002)
∏ ([PMX70B]) 1 x DAB antenna
(N1EYYY000015)
R6/LR6, AA
SC-PMX70-70B_EGEBGN-RQT9988-B.book 3 ページ ２０１４年１２月２９日 月曜日 午後１時２１分
